How Electrically Insulating Boots are Tested Manufacturers must test every piece of dielectric footwear to EN 50321-1:2018. The test involves filling the boot with water and submerging it in a water bath, an electrode is placed inside the boot, with a second electrode connected to the metal frame of the bath. A test voltage is then applied. Boots are tested at the appropriate leakage current test voltage for their class rating (see table below) for three minutes during which the leakage current must not exceed the maximum permitted value for the class rating. For certification, boots are tested to the withstand test voltage, but this is considered a destructive test. Workmaster™ test all of their boot and overboots with alternating current (AC) as standard, but Direct Current (DC) testing is available on request. Class Rating Maximum Working Voltage Withstand Test Voltage Leakage Current Test Voltage Maximum Leakage Current Class 00 500V 5kV 2.5kV 3mA Class 0 1kV 10kV 5kV 5mA (8mA) Class 1 7.5kV 20kV 10kV 10mA (16mA) Class 2 17kV 30kV 20kV 18mA Class 3 26.5kV 40kV 30kV 20mA Class 4 36kV 50kV 40kV 24mA

0 Cart$0.00 USD

How Electrically Insulating Boots are Tested Manufacturers must test every piece of dielectric footwear to EN 50321-1:2018. The test involves filling the boot with water and submerging it in a water bath, an electrode is placed inside the boot, with a second electrode connected to the metal frame of the bath. A test voltage is then applied. Boots are tested at the appropriate leakage current test voltage for their class rating (see table below) for three minutes during which the leakage current must not exceed the maximum permitted value for the class rating. For certification, boots are tested to the withstand test voltage, but this is considered a destructive test. Workmaster™ test all of their boot and overboots with alternating current (AC) as standard, but Direct Current (DC) testing is available on request. Class Rating Maximum Working Voltage Withstand Test Voltage Leakage Current Test Voltage Maximum Leakage Current Class 00 500V 5kV 2.5kV 3mA Class 0 1kV 10kV 5kV 5mA (8mA) Class 1 7.5kV 20kV 10kV 10mA (16mA) Class 2 17kV 30kV 20kV 18mA Class 3 26.5kV 40kV 30kV 20mA Class 4 36kV 50kV 40kV 24mA

News

Why SimPole is not like any other pole!

nonconductive safe

Why SimPole is not like any other pole!

High strength-to-weight ratio Excellent corrosion resistance Thermal insulation capabilities Electrical insulation properties Durability and longevity Resistance to heat and chemicals Dimensional stability Ultra High Mod Water Fed Poles SimPole Prototype History https://www.facebook.com/PhillipAlexander68/videos

Phillip Alexander

August 29, 2025

Warranty SimPole

Warranty SimPole

SimPole Warranty

Phillip Alexander

April 3, 2025

SimBlue

nonconductive

SimBlue

Ultra High Mod inside two protected non-conductive fibers Tested to 20,000 volts Free training manual on how to use a water-fed pole $200 add-on 6-foot extension pole to make 40 feet fit on all Section 8 of SimPoles STOP Risking...

Phillip Alexander

March 24, 2025

How We Got SimPoles

nonconductive

How We Got SimPoles

Simpole.com the best Little Big Waterfed pole company" Philip Alexander wasn't your typical inventor. Sure, he was brilliant, but there was a kindness about him that made him stand out. Back in Prescott, Arizona, he'd started tinkering with the idea...

Phillip Alexander

December 11, 2024

New Modular Solar and gutter pole!

New Modular Solar and gutter pole!

Phillip Alexander

December 7, 2024
